| Battery |
| Automatic battery test | Yes |
| Battery life (max) | 6 anno/i |
| Battery recharge time | 3 Hour |
| Battery technology | Sealed Lead Acid (VRLA) |
| Cold start | Yes |
| Hot-swap battery | Yes |
| Number of batteries supported | 1 |
| Replacement battery cartridge | APCRBC132 |
| Design |
| Certification | EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH |
| Display | LCD |
| Display type | LCD |
| Form factor | Rackmount |
| LED indicators | Yes |
| Product colour | Black |
| Rack capacity | 2U |
| RoHS compliance | Yes |
| Features |
| Automatic Voltage Regulation (AVR) | Yes |
| Auto-restart | Yes |
| Input frequency | 50/60 Hz |
| Input operation voltage (max) | 302 V |
| Input operation voltage (min) | 151 V |
| Noise level | 45 dB |
| Output frequency | 50/60 Hz |
| Output operation voltage (max) | 240 V |
| Output operation voltage (min) | 220 V |
| Output power | 700 Watt |
| Output power capacity | 1 kVA |
| Output voltage Total Harmonic Distortion (THD) | 5 % |
| Response time | 10 Millisecond |
| Surge energy rating | 459 J |
| Surge protection | Yes |
| Temperature voltage compensation | Yes |
| UPS topology | Line-Interactive |
| Waveform | Sine |
| Web-based management | Yes |
| Logistics data |
| Harmonized System (HS) code | 85078000 |
| Products per pallet | 8 pz |
| Operational conditions |
| Non-operating altitude | 0 – 15000 m |
| Operating altitude | 0 – 3000 m |
| Operating relative humidity (H-H) | 0 – 95 % |
| Operating temperature (T-T) | |
| |
| |
|
| |
| |
| |
| |
|
| |
| |
| |
| |
| |
|
| |
| |
| |
| |
| |
| |
| |
| |
|
| |
| |
| |
| |
|
| |
| |
|
| |
| |
